HP Service Manuals

All manuals are used, good condition, factory originals, unless noted otherwise.
Reproductions are professionally made, with full fold-outs, and spiral bound.

Model/Description	Price/Condition
HP 191A TV Waveform Oscilloscope Operating and Service	$35 Original
HP 209A Sine/Square Oscillator Operating and Service	SORRY, SOLD $35 Original
HP 400E/EL AC Voltmeter Operating and Service, punched for 3 ring binder, like new cond.	SORRY, SOLD $15 Original
HP 486A Thermistor Mounts Operating and Service	$5 Original
HP 654A Test Oscillator Operating and Service	SORRY, SOLD $39 (Repro)
HP 1220A Oscilloscope Operating and Service	$39 Original
HP 1220A/21A Oscilloscope Operating and Service	$39 Original
HP 1222A Oscilloscope Operating and Service, includes updates	$45 Original
HP 1707A Oscilloscope Operating and Service	$45 Original Only Fair Condition
HP 3310A/B Function Generator Operating and Service	SORRY, SOLD $45 Original
HP 3435A Digital Multimeter Operating and Service	$49 Original
HP 3438A Digital Multimeter Operating and Service	$39 Original 2 Copies
HP 3468A Digital Multimeter Operating	$25 Original
HP 3468A/B Digital Multimeter Operating and Service	SORRY, SOLD $65 Original
HP 3478A Digital Multimeter Operating and Service	$69 New, Original
HP 3490A Digital Multimeter Operating and Service Spiral Bound	$65 Original
HP 3580A Spectrum Analyzer Operating and Service, includes both early mechanical and later LED frequency displays, full backdating.	SORRY, SOLD $75 (Repro)
HP 3581A/C Wave Analyzer Operating and Service	SORRY, SOLD $65 (Repro)
HP E3631A Triple Power Supply Operating and Service, 2 vols. Spiral Bound	$69 New, Original
HP 3702B IF/BB Receiver Operating and Service	$55 Original
HP 5150A Thermal Printer Operating and Service	$65 Original
HP 5315A/B 100MHz Universal Counter Operating and Service	$55 Original
HP 5315A/B 100MHz Universal Counter Operating and Service, like new with many updates	$65 Original
HP 5316A 100MHz Universal Counter (with GPIB) Operating and Service	$65 Original
HP 6033A System DC Power Supply Operating and Service	SORRY, SOLD $65 Original
HP 6205C Dual DC Power Supply Operating and Service	$49 Original
HP 6227B DC Power Supply Operating and Service	$35 Original SORRY, SOLD
HP 6255A Dual DC Power Supply Operating and Service	$55 Original 2 Available
HP 6256B, 6263B, 6264B, 6265B, 6266B, 6267B, 6271B, 6274B DC Power Supply Operating and Service	$49 Original
HP 6289A DC Power Supply Operating and Service	$49 Original
HP 6621A, 6622A, 6623A, 6624A, 6672A System DC Power Supply Operating	2 Copies $39 Original, like new
HP 8013B Pulse Generator Operating and Service, spiral bound.	$55 (Repro)
HP 8441A Preselector Operating and Service Spiral Bound	SORRY, SOLD $25 Original
HP 8590E-series and L-series Spectrom Analyzer Quick Reference Guide Small portable operating guide, still factory sealed.	$65 Original 1 Available
HP 8614A Microwave Signal Generator Operating and Service	SORRY, SOLD $20 Original
HP 8616A Microwave Signal Generator Operating and Service	$20 (Repro)
HP 8691A, 8692A, 8693A, 8694A RF Plug-ins Operating and Service, includes mod data	SORRY, SOLD $22 Original
HP 8691B, 8692B, 8693B, 8694B RF Plug-ins Operating and Service, includes H01/H02 opts.	SORRY, SOLD $25 Original
HP 8699B RF Plug-in Operating and Service	$15 (Repro)
HP 34401A Digital Multimeter Service, Spiral bound, 1 vol.	$45 Originals
HP 34401A Digital Multimeter Operating and Service, Spiral bound, 2 vols.	$69 NEW Originals
HP 53131A, 53132A, 53182A 225Mhz Counter Board Level Service, Spiral bound, 1 vol.	$59 NEW Original
HP 86222A/B Microwave Sweeper Plug-in Operating and Service	$85 Original
HP 86290A Microwave Sweeper Plug-in Operating and Service	$65 (Repro)

E-mail us

Want something? Click here to e-mail us! We accept Visa / MC for fast order processing.

Keithley Service Manuals Keithely has an excellent on-line manual service (PDF files), covering all older and newer service and user manuals, including newer ones in Japanese and Chinese. There is no cost for this service, all part of their excellent customer support. Many other makers could learn from this site!

CLICK to see their manual download site!

Misc. Manuals

Description	Price/Condition
ESI (Electro Scientific Industries) DB42, DB52 and DB62 Dekabox Decade Resistors Operators, and service manual for this reistor box family.	$19 ORIGINAL Like new
Wavetek / PMI 1045/01 RF Power Meter Full operating and service on this very popular instrument. This manual is very hard to find, and these are NEW!. Includes all updates, from early PMI to late Wavetek versions, and /01 multi-sensor option.	$95 ORIGINAL Like new Have 2
Wavetek / PMI 1045 RF Power Meter Full operating and service on this very popular instrument. This manual is very hard to find. Includes all updates, from early PMI to late Wavetek versions, and /01 multi-sensor option, even thiough not marked on the front. This is a slightly earlier version than the copy above, but the data is the same, very good condition.	$85 ORIGINAL, 2 available

7000/5000 series Scope and TM500/TM5000 Plug Ins	Price/Condition
5A20N Differential Amplifier Plug in	$35
5A22N Differential Amplifier Plug in includes manual change information.	$35
5B12N Dual Timebase Plug in includes manual change information.	$29
5CT1N Curve Tracer Plug in late August 1982 revision.	$49
7A13 Vertical Plug in	$35
7A16 Vertical Plug in	$35
7A18/18N Vertical Plug in	$35 SORRY, SOLD
7A19 Vertical Plug in	$39
7A24 Dual Ch. Vertical Plug in	$35
7A26 Dual Ch. Vertical Plug in	$35
7B53A Horizontal Dual Sweep Plug in	$45 SORRY, SOLD
7B85 Horizontal Delayed Sweep Plug in	$45 2 Available
7D12 D-to-A Converter Plug in	$35
DC509 Counter and Options Plug in (81 Rev.)	$45
DC5009 Counter and Options Plug in (81 Rev.)	$45 SORRY, SOLD
FG507 2MHz Function Generator Plug in (80 Rev.)	$39 (Repro)
FG5010 FG507 20MHz Function Generator Plug in (83 Rev.)	$55
PS503A Dual Power Supply Plug in	$29 4 Available
SC503 Storage Scope Plug in late 1988 revision, many updates.	$45 (Repro)
Scopes/ Scope Frames	Price/Condition
212 Portable Scope, Rev. B, 1975 (Op and Service) New condition.	$45
308 Portable Data Analyzer (1986 Rev.)	$49 (Repro)
321A Portable Scope	SORRY, SOLD $45
422/R422 Portable Scope	$39
434/R434 Portable Storage Scope	$39
442 Portable Scope complete with updates to 1978.	$39
453/R453 Portable Scope	SORRY, SOLD $39 (Repro)
453A/R453A Portable Scope	$39 (Repro)
454A/R454A Portable Scope (82 Rev.)	SORRY, SOLD $49
464/466 DM44 Portable Storage Scope Operator's Manual (small format for top pouch)	$19
465M Modular Portable Scope	SORRY, SOLD $65 (Repro)
475A 200Mhz Portable Scope Mint condition factory original, 1976 edition with updates to 1978. Very heavy.	$75
502 Dual Beam Scope Operation and service	$29
512 Low Frequency Scope Operation and service, orignal green cover manual, very hard to find.	$29
D54 / D54R Telequipment 10Mhz Portable Scope (op/service)	$39
T932/T935 35Mhz Portable Scope (Oct. 75 Rev.)	$45 (Repro)
T932/T935 35Mhz Portable Scope (Oct. 75 Rev.), like new, with updates/revisions	$59 Original
1502 Time Domain Reflectometer (TDR) late 1989 revision, many updates.	$45 (Repro)
2232 Small format (fits in the pouch) Operator's Manual	SORRY, SOLD $35
2246 1Y, 2R and Mod. A Small format (fits in the pouch) Operator's Manual	$45
2465 Full manual (very heavy, $18 to ship) (1985 Rev.)	SORRY, SOLD $75
5103N Mainframe Scope Operation and service, 1971 edition	$35
5110 Mainframe Scope Operation and service, includes updates to 1978	$39
5440/R5440 Scope Mainframe (86 Rev.)	$59
7313 Storage Scope Frame	$49
7514 Storage Scope Frame	$49 (Repro & Original)
7603/R7603 Scope Mainframe	$59 1 Available
R7704 Scope Mainframe	$49 2 Available
7904 Scope Mainframe (S/N B260000+, Mar. 83 Rev.)	SORRY, SOLD $55
7904A Scope Mainframe + Options (May 89 Rev.)	$65 (Repro)
TDS500C, TDS600B, TDS700C Digitizing Oscilloscope User's manual and software programming diskette. Large factory binder with diskette pockets, Tek P/N 070-9869-00.	$65 ORIGINAL
Other Units, TM500/5000 Frames	Price/Condition
184 Time Mark Generator	$25
191 Constant Amplitude Signal Generator Operation and service, includes serial number updates to 2130.	$35
TM506 TM500 mainframe	$45
TM515 TM500 portable mainframe	$45 2 Available
TM5006 TM5000 mainframe (multilanguage)	$45
