2SA, 2SB, 2SC, 2SD, 2SJ, 2SK Transistors
(Note: the (2S) prefix is often dropped on package markings!

2SA- Transistor, high frequency, PNP
2SB- Transistor, low frequency, PNP
2SC- Transistor, high frequency, NPN
2SD- Transistor, low frequency, NPN
2SJ- FET, P channel
2SK- FET, N channel
3SK- MOSFET, N channel


PART NUMBER
DESCRIPTION
QTY.
PRICE EACH
2SA562Y
2SA562Y
A562Y
TO-92 Transistor
17
$ 2 ea.
A673
A673
2SA673
TO-92 Transistor, may also be 2SA673D, see package marking.
20
$ 2 ea.
A684
A684
2SA684
Super TO-92 Driver Transistor.
20
$ 4 ea.
A699
2SA699
Matsushita
Matsushita TO-202 Transistor (ECG187A)
30
$ 5 ea.
A738
2SA738
TO-126 Power Transistor (ECG185)
2
$ 6 ea.
A778
A778
2SA778
TO-92 Transistor, may also be 2SA778A, see package marking.
20
$ 2 ea.
2SA807
A807
Sanken
Sanken, TO-3 Power Transistor
25
$ 9 ea.
A844
A844
2SA844
TO-92 Transistor, may also be 2SA844D, see package marking.
20
$ 2 ea.
A886
A886
2SA886
TO-126 Power Transistor.
20
$ 5 ea.
A886-Q
A886-Q
2SA886-Q
Matsushita
Matsushita TO-126 Power Transistor, insulated case.
20
$ 6 ea.
A966A
2SA966A
A966A
TO-92/Tall Driver Transistor
20
$ 3 ea.
A985
2SA985
TO-220 Power Transistor (ECG398)
12
$ 3 ea.
A1015
A1015
2SA1015
TO-92 Transistor, may also be 2SA1015Y, see package marking.
20
$ 2 ea.
A1016
2SA1016
TO-92 Transistor
10
$ 2 ea.
2SA1175
A1175
2SA1175
NEC
NEC PNP high gain (200 min.) audio driver, 250mW. Taped and reeled.
90
$ 3 ea.
A1450
2SA1450
A1450
TO-92 Transistor
20
$ 2 ea.
A1538
2SA1538
A1538
Insulated TO-126 Power Transistor, preformed leads
20
$ 8 ea.
2SA2023
A2023
Insulated TO-126 Power Transistor, factory bags of 200. High speed PNP 60V/5A, 100MHz Ft.
1,000
$ 3 ea.
200/$125
B536
2SB536
NEC
NEC TO-220 Power Transistor (ECG292)
2
$ 3 ea.
B562C
2SB562C
B562C
TO-92/Tall Driver Transistor
20
$ 3 ea.
B566
2SB566
B566
Hitachi
Hitachi TO-220 Power Transistor
20
$ 7 ea.
B633
2SB633
TO-220 Power Transistor (ECG197)
4
$ 3 ea.
B717
B717
2SB717
Hitachi
Hitachi TO-202 Power Transistor, (green case), may also be 2SB717C, see case markings.
18
$ 6 ea.
B739
B739
2SB739
Super TO-92 Driver Transistor, may also be 2SB739C, see case markings.
20
$ 4 ea.
B795
2SB795
B795
NEC
NEC TO-126 Power Transistor (green case)
20
$ 7 ea.
SANYO 2SB883
2SB883
B883
Sanyo
Sanyo PNP Darlington Power Transistor
12
$ 11 ea.
B951
B951
2SB951
Insulated TO-220 Power Transistor.
20
$ 7 ea.
B1077
2SB1077
B1077
TO-220 Power Transistor (green case)
20
$ 7 ea.
B1109C
2SB1109
B1109
Hitachi
Hitachi TO-126 Power Transistor (green case), may also be 2SB1109C, see case marking.
20
$ 7 ea.
2SB1287
B1287
Rohm
ROHM, Insulated TO-220 Power Transistor (green case).
28
$ 7 ea.
2SB1535
2SB1535
B1535
Miniature (solderable tab) Power Transistor
20
$ 3 ea.
2SC1017
C1017
Matsushita
Matsushita TO-202 Power Transistor (ECG299)
9
$ 3 ea.
C1162C
2SC1162C
C1162C
Hitachi
Hitachi TO-126 Power Transistor
SORRY, SOLD
$ 5 ea.
2SC1172B
2SC1172B
C1172B
Toshiba
Toshiba TO-3 HV Transistor
50
$ 9 ea.
2SC1368
C1368
Hitachi
Hitachi TO-126 Transistor
5
$ 3 ea.
C1384
2SC1384
C1384
Matsushita
Matsushita Driver Transistor
20
$ 4 ea.
C1627Y
2SC1627Y
C1627Y
TO-92 Transistor
20
$ 2 ea.
C1685
2SC1685
C1685
Matsushita
Matsushita TO-92 Transistor
20
$ 2 ea.
C1730
2SC1730
C1730
TO-92 Transistor
20
$ 2 ea.
2SC1740
2SC1740
C1740
TO-92 Transistor
16
$ 2 ea.
2SC1941
C1941
Mid-power Transistor (ECG399)
5
$ 3 ea.
2SC1951
C1951
Mid-power Transistor (ECG382)
10
$ 3 ea.
SANKEN 2SC1986
2SC1986
C1986
Sanken
Sanken TO-220 Power Transistor
25
$ 5 ea.
2SC2029/1
C2029/1
Fujitsu
Fujitsu TO-220 Power Transistor (ECG235)
3
$ 5 ea.
C2120
2SC2120
C2120
TO-92 Transistor
8
$ 2 ea.
C2168
2SC2168
C2168
Sanken
Sanken TO-220 Power Transistor
20
$ 7 ea.
C2209-Q
2SC2209-Q
C2209-Q
Matsushita
Matsushita TO-126 Power Transistor
20
$ 8 ea.
C2274
2SC2274
C2274
TO-92 Transistor
20
$ 2 ea.
C2383
2SC2383
C2383
Super TO-92 Driver Transistor
20
$ 4 ea.
C2911
2SC2911
C2911
TO-126 Power Transistor
20
$ 7 ea.
2SC3060
2SC3060
C3060
Fujitsu
Fujitsu TO-3 Power Transistor
3
$ 11 ea.

2SC3271F
C3271F
Insulated TO-220 Power Transistor, insulated case.
65
$ 8 ea.
C3504
2SC3504
C3504
Super TO-92 Driver Transistor
20
$ 4 ea.
C3746
2SC3746
C3746
Insulated TO-220 Power Transistor
20
$ 8 ea.
2SC3998, NEC
2SC3998
C3998
NEC
NEC High Power Horizontal Deflection Transistor, NPN, Si, factory bagged stock. 1500V/25A, for ultra hi-def deflection circuits.
10
$ 18 ea.
2SC4075
2SC4075 (D)
C4075 (D)
Sanyo
Sanyo NPN HV Power Transistor, insulated case with formed leads, 300V BVceo, 0.2A Ic, 10W Pd, (D) category is HFE from 60-120.
100
$ 5 ea.
2SC4123
C4123
Insulated TO-247 Power Transistor
50
$ 11 ea.
C4212 (H)
2SC4212 (H)
C4212 (H)
Insulated TO-126 Power Transistor
20
$ 7 ea.
2SC4354
2SC4354
C4354
Rohm
ROHM Insulated clamp mount Power Transistor
20
$ 4 ea.
(2S) C4533
2SC4533
C4533
Matsushita
Matsushita Insulated TO-220 Power Transistors (formed leads). These were all individually bagged in huge RCA service parts bags, we have stripped the bags for ease of storage, and re-packed in a large anti-static pouch. NPN planar 400V Vceo, 3A Ic, 30W, 10MHz Ft.
250
$ 8 ea.
2SC4834
2SC4834
C4834
SHINDENGEN
Shindengen Insulated (2kv) TO-220/Block Power Switching Transistors (TP8V40FS). These were all individually bagged in huge RCA service parts bags, we have stripped the bags for ease of storage, and re-packed in a large anti-static pouch. NPN planar 400V Vceo, 8A Ic, 45W, 13MHz Ft.
150
$ 7 ea.
2SC5299, NEC
2SC5299
C5299
NEC
NEC High Power Horizontal Deflection Transistor, NPN, Si, factory bagged stock. 1500V/10A, for ultra hi-def deflection circuits. Fully insulated package.
25
$ 15 ea.
Toshiba (2S) C5386
2SC5386
C5386
Toshiba
Toshiba High Power Horizontal Deflection Transistor, NPN, Si, factory bagged stock. 1500V/8A, for high resolution deflection circuits, fully insulated package.
50
$ 14 ea.
Toshiba 2SC5589, CLICK for bigger PIC!
CLICK for bigger PIC!

2SC5589
C5589
Toshiba
Toshiba High Power Horizontal Deflection Transistor, NPN, Si, factory bagged stock (complete with insulators). 1500V/15A, for high resolution deflection circuits.
25
$ 14 ea.
D330
2SD330
D330
TO-220 Power Transistor
20
$ 7 ea.
D401A
2SD401A
D401A
NEC
NEC TO-220 Power Transistor
20
$ 7 ea.
D467
2SD467
D467
TO-92 Transistor
20
$ 2 ea.
D468C
2SD468C
D468C
Driver Transistor
20
$ 5 ea.
D560
2SD560
D560
NEC
NEC TO-220 Power Transistor
20
$ 7 ea.
D612K
2SD612K
D612K
TO-126 Power Transistor
18
$ 6 ea.
D637
2SD637
D637
Flatpack Transistor
20
$ 2 ea.
D655
2SD655
D655
TO-92 Transistor
20
$ 2 ea.
D667D
2SD667D
D667D
Driver Transistor
20
$ 4 ea.
D758
2SD758
D758
Hitachi
Hitachi TO-202 Power Transistor
25
$ 5 ea.
2SD820
2SD820
D820
Toshiba
Toshiba TO-3 HV Transistor
75
$ 12 ea.
D863
2SD863
D863
Super-92 Driver Transistor
20
$ 4 ea.
2SD946A-S
D946A-S
ON, Insulated TO-126 Power Transistor
40
$ 9 ea.
2SD1055R
2SD1055R
D1055R
Flatpack Transistor
50
$ 1 ea.
D1293M
2SD1293M
D1293M
Flatpack Transistor, may also be D1293 with no siffix, see package markings
20
$ 2 ea.
2SD1392
K2134
NEC
NEC, TO-220 Power Transistor
29
$ 6 ea.
2SD1431
D1431
Toshiba
Toshiba, TO-247 Power Transistor
50
$ 12 ea.
(2S) D1455 Hitachi
2SD1455
D1455
Hitachi
Hitachi TO-247 High Voltage/High Current NPN Deflection transistor with base and collector clamping diodes. These were individually bagged in huge plastic bags by RCA (their service parts), we removed them to save space, and re-stored them in a large anti-static pouch.
120
$ 12 ea.
Insulated (2S) D1455
2SD1455
D1455
Insulated
Hitachi
Hitachi TO-247 High Voltage/High Current NPN Deflection transistor with base and collector clamping diodes. These were individually bagged in huge plastic bags by RCA (their service parts), we removed them to save space, and re-stored them in a large anti-static pouch. These have fully insulated cases, but have no obvious different part number that we can see.
7
$ 14 ea.
D1783
2SD1783
D1783
ROHM
Rohm TO-220 Power Transistor
20
$ 8 ea.
Rohm 2SD2023, CLICK for bigger PIC!
CLICK for bigger PIC!

2SD2023
D2023
2SD2023ROHM
Rohm TO-220 Power Transistor NPN Si Driver, 80V Vcbo, 60V Vceo, 3A Ic, 40W, all are Group E (gain = 100-200), 8Mhz Ft. Driver, audio and DC power switch. Factory boxed in 500's, with 5 bags of 100 inside. Same as Sanyo 2SD2027, Toshiba 2SD880, NEC 2SD1567, Matsushita 2SD856. This is a great improvement over TIP31A parts, with higher gain and Ft.
10,000
$2 ea.
$130/100
$490/500
Sanken 2SD2493
2SD2493
D2493
Sanken
Sanken, TO-247 NPN Power Darlington Transistor, Vceo 110V, Ic 6A, 60W, very high gain, over 10,000 typically at 1A. Good for power supply regulator and audio applications, 60MHz Ft. Complimentary part is 2SB1624.
120
$ 12 ea.
2SJ48 / J48 MOSFET
2SJ48
J48
Hitachi
Hitachi TO-3 P-channel enhancement MOSFETS, hard to find, PLUS every unit is TESTED before shipment, and packed in an anti-static bag.
15
$ 22 ea.
2SK117
2SK117
K117
Toshiba
Toshiba TO-92 low noise N-channel FET, for audio applications (1.0dB noise figure), taped and reeled.
150
$ 5 ea.
2SK133 / K133
2SK133
K133
Hitachi
Hitachi TO-3 N-channel enhancement MOSFETS, hard to find, PLUS every unit is TESTED before shipment, and packed in an anti-static bag.
10
$ 22 ea.
K332
2SK332
K332
Miniature Dual-FET
18
$ 12 ea.
2SK526, K526
2SK526
K526
Insulated TO-220 Power FET
25
$ 9 ea.

2SK557
K557
Hitachi
Hitachi TO-247 High Power FET
12
$ 12 ea.
2SK699
2SK699
K699
TO-126 Power FET
25
$ 8 ea.
Toshiba 2SK793
2SK793
K793
Toshiba
Toshiba, Plastic Power N-Chan. MOSFET, 150W, 850V/5A max.
20
$ 11 ea.
2SK890, K890
2SK890
K890
TO-220 Power FET
25
$ 9 ea.
2SK1605, NEC
2SK1605
K1605
NEC
NEC High Power FET, factory bagged stock. Fully insulated package.
25
$ 15 ea.
2SK1904
K1904
Insulated TO-220 Power FET
50
$ 9 ea.
2SK2134
K2134
NEC
NEC, TO-220 Power FET
25
$ 9 ea.
2SK2299
2SK2299
K2299
ROHM
ROHM Insulated TO-220 Power FET
12
$ 9 ea.

2SK2333
K2333
Sanyo
Sanyo (?) Insulated TO-220 Power FET
12
$ 9 ea.

2SK3155
K3155
Hitachi
Hitachi Insulated TO-220 Power FET
12
$ 9 ea.



CLICK to visit!
CLICK to visit!
Need data on these parts or other semiconductors? Try this free datasheet archive!


ICs and Other Transistor/Rectifier Types
(Note: Includes European Pro-electron numbers


PART NUMBER
DESCRIPTION
QTY.
PRICE EACH
Matsushita AN315
AN315
Matsushita
Matsushita/Panasonic AN315 single channel audio power amplifier, 13V/4.5W/4 ohms.
14
$ 9 ea.
AN612
Matsushita
Matsushita/Panasonic AN612, SIP IC, SSB balanced modulator circuit. (ECG1249)
6
$ 8 ea.
AN5411
Matsushita
Matsushita/Panasonic AN5411, 24 Pin DIP IC, Deflection Signal Processor. (ECG1417)
4
$ 8 ea.
AN5835
Matsushita
Matsushita/Panasonic AN5835, SIP IC, V(cc)14.4V, 60mA 920mW DC volume, tone control IC.
1
$ 11 ea.
AN7115
Matsushita
Matsushita/Panasonic AN7115, DIP IC w/heatsink, single channel audio power amp., 2.1W, 4 ohms, 13V supply. (ECG1381)
6
$ 8 ea.
AN7218
Matsushita
Matsushita/Panasonic AN7218, 16 Pin DIP IC, AM tuner, FM/AM IF amp. (ECG1563)
3
$ 8 ea.
BA536
Power device (ECG1619)
5
$ 10 ea.
TO-225AA
BD135
PhilipsMotorola
NPN 1.5A/45V/10W, b=40, power transistors, TO-225AA plastic power case, complementary to BD136. Philips and Motorola, Phillips in tubes of 50.
1250
$ 2 ea.
$80/50
$150/100
TO-225AA
BD136

Motorola PNP 1.5A/45V/10W, b=40, power transistors, TO-225AA plastic power case, complementary to BD135. Motorola
500
$ 2 ea.
$150/100
ASI BD746C
BD746C

ASI PNP 20A/100V/115W, b=40, power transistors, TO-3P plastic power case, complementary to BD745 series. Audio and switching power applications. ASI
100
$ 6 ea.
BF422
BF422
Philips
NPN 250V, b=50, transistors, Formed TO-92. Taped, appear to be Philips
150
$ 2 ea.
BUF410A
BUF410A
ST
Power Transistor, ST.
10
$ 8 ea.
BU2527AX
BU2527AX
Philips
BU2527AX NPN high voltage (1500V/12A) high speed horiz. deflection power transistor, fully insulated package. Philips
80
$ 14 ea.
TO-3 Power
BUZ64
N-Channel Enhancement POWER MOSFET, Philips
20
$ 20 ea.
ST BYW51F
BYW51F
ST
Hi Speed Dual Common-Cathode Rectifier, Insulated TO-220 package, 200V/10A/25ns.
100
$ 8 ea.
14 pin DIP
CA3046
RCARCA, NPN Transistor array, very hard to find! Data available on request with orders.
40
$ 6 ea.
14 pin DIP
CA3054
RCARCA, Dual Differential (isolated) Amplifier Transistor array, very hard to find! Data available on request with orders.
125
$ 6 ea.
16 pin DIP
CA3096E
RCARCA, NPN/PNP Transistor Linear IC, very hard to find! Data available on request with orders.
25
$ 8 ea.
HA1308
Hitachi
Hitachi Power Device (ECG1030)
2
$ 5 ea.
HA1339A
Hitachi
Hitachi Power Device (ECG1169)
SORRY, SOLD
$ 5 ea.
HA1392
HitachiHitachi Power Device (ECG1606)
5
$ 5 ea.
LA3361
Samsung IC (ECG1248)
3
$ 4 ea.
LA4100
Power DIP Device (ECG1180)
4
$ 5 ea.
LA7840
LA7840
SANYO
Vertical Deflection Output Driver
5
$ 8 ea.
LC7131
Sankyo IC (ECG1475)
2
$ 5 ea.
MC3359P
Motorola IC (ECG853)
10
$ 2 ea.
TA7204P
Toshiba
Toshiba Power Device
1
$ 5 ea.
TA7205AP
Toshiba
Toshiba Power Device
3
$ 5 ea.
TDA1524A
Philips DIP stereo audio control system.
6
$ 8 ea.
TDA1675
SIP power package, Deflection Amp.
10
$ 10 ea.
TDA2613
Phlips, SIP power package, Audio Power Amp.
4
$ 12 ea.
TDA8177
TDA8177
ST
Vertical Deflection Booster Power IC, ST.
38
$ 8 ea.
NEC UPC1025H
UPC1025H
NEC
NEC Audio Power Amplifier
20
$ 8 ea.
UPC1182H
NEC
NEC Power Device
12
$ 5 ea.
UPC1230H
NEC
NEC Power Device (ECG1389)
8
$ 6 ea.
UPC1230H2
UPC1230H2
NEC
NEC Power Device (ECG1389)
32
$ 6 ea.


STK Modules STK Series Data Sheets
General Sanyo Index of Driver Hybrids, CLICK HERE
STK 41X1 II Series Audio Amplifiers, CLICK HERE
STK 4100-4200 Series MK2 Amplifiers, CLICK HERE
STK-Detailed Family Index, CLICK HERE

IG/SI/STK/STR/VPS Series Hybrid Power Modules
Audio and Video Amplifiers, Drivers and Voltage Regulators

PART NUMBER
DESCRIPTION
QTY.
PRICE EACH
IG02950
IG02950 / IG 02950
YamahaPre-Driver, factory boxed.
NEW
SORRY, SOLD
$ 24 ea.
IG02980 / IG 02980
YamahaPower Amplifier.
NEW
SORRY, SOLD
$ 27 ea.
Yamaha IG04540 / STK3056
IG04540 / IG 04540
STK3056 / STK-3056
YamahaVoltage Amplifier, factory boxed. Dual marked, IG and STK.
NEW
Just 1
$ 29 ea.
IG04550 / IG 04550
STK3076 / STK-3076
YamahaVoltage Amplifier. Dual marked, IG and STK.
NEW
Just 1
$ 33 ea.
IG04880 / IG 04880
STK3156 / STK-3156
YamahaVoltage Amplifier, factory boxed. Dual marked, IG and STK.
NEW
SORRY, SOLD
$ 33 ea.
PART NUMBER
DESCRIPTION
QTY.
PRICE EACH
Sanken SI-1050G
SI-1050G
Sanken
SANKEN 50W/8 Ohm Audio Power Amplifier (metal housing, 10 pins). 80VDC Max supply. New, old stock, never installed! These were very popular, but are now almost impossible to find, here's your chance!
Multi-purpose linear amplifiers for commercial and industrial applications
Less than 0.5% harmonic distortion at full power level
1/2dB response from 20 Hz to 100 KHz
Single or split (dual) power supply

CLICK HERE for Internal Schematic
CLICK HERE for Single Supply Amp
CLICK HERE for Split Supply Amp
SORRY, SOLD
$ 59 ea.
SI-3240GA
Sanken
SANKEN Audio Power Amplifier (silver metal housing, 8 pins).
NEW
Just 1
$ 26 ea.
PART NUMBER
DESCRIPTION
QTY.
PRICE EACH
STK011 / STK-011
SANYO SANYO Audio Power Amplifier.
NEW
Just 5
$ 15 ea.
STK014
STK014 / STK-014
Stereo Audio Power Amplifier.
NEW
Just 2
$ 29 ea.
STK014 / STK-015
SANYOSANYO Audio Power Amplifier.
NEW
Have 9
$ 18 ea.
STK016 / STK-016
Audio Power Amplifier.
NEW
SORRY, SOLD
$ 15 ea.
STK020 /STK-020
Audio Power Amplifier.
NEW
Just 3
$ 18 ea.
TCG1090
STK022
TCG High Power Audio Power Amplifier. marked TCG1090, equiv. to STK-022
NEW
SORRY, SOLD
$ 28 ea.
STK023
STK023 / STK-023
Audio Power Amplifier.
NEW
SORRY, SOLD
$ 22 ea.
STK025 / STK-025
Audio Power Amplifier.
NEW
Just 1
$ 25 ea.
STK0025 / STK-0025
Darlington Power Pack.
NEW
Just 1
$ 22 ea.
STK0036 / STK-0036
Audio Power Amplifier.
NEW
Just 4
$ 33 ea.
STK0039
STK0039 / STK-0039
35W Audio Power Amplifier, dual PSU, similar to NTE1282.
Just 1
$ 33 ea.
STK040 / STK-040
Stereo Audio Power Amplifier.
NEW
SORRY, SOLD
$ 33 ea.
STK040 I /STK-040 I
Stereo Audio Power Amplifier.
NEW
SORRY, SOLD
$ 35 ea.
STK040 II / STK-040 II
Stereo Audio Power Amplifier.
NEW
Just 2
$ 39 ea.
STK050 /STK-050
Audio Power Amplifier
SORRY, SOLD
$ 36 ea.
STK-054
STK054 / STK-054
20W SONY Audio Power Amplifier, 2 PSU, sim. to NTE1028.
NEW
Just 1
$ 29 ea.
STK055N / STK-055N
Audio Power Amplifier.
NEW
Just 1
$ 29 ea.
STK056A / STK-056A
SONY Audio Power Amplifier
NEW
Just 1
$ 29 ea.
STK075 / STK-075
Audio Power Amplifier.
NEW
Just 1
$ 33 ea.
STK078 / STK-078
Audio Power Amplifier.
NEW
Just 1
$ 33 ea.
STK0080 / STK-0080
Darlington Power Pack.
NEW
SORRY, SOLD
$ 18 ea.
STK084 / STK-084
Audio Power Amplifier.
NEW
Just 1
$ 33 ea.
STK086 / STK-086
Audio Power Amplifier.
NEW
Just 2
$ 33 ea.
STK0100 / STK-0100
Darlington Power Pack
NEW
Just 1
$ 28 ea.
STK0100 II
STK0100 II
Audio Power Amplifier.
NEW
1
$ 36 ea.
STK0231
STK0231
SANYO Audio Power Amplifier.
NEW
SORRY, SOLD
$ 33 ea.
STK-401
STK401 / STK-401
Audio Power Amplifier.
NEW
Just 3
$ 29 ea.
STK430 / STK-430
Stereo Audio Power Amplifier.
NEW
Just 3
$ 22 ea.
STK433 / STK-433
Stereo Audio Power Amplifier.
NEW
Just 2
$ 22 ea.
STK435
STK435 / STK-435
Stereo Audio Power Amplifier, similar to NTE1218.
NEW
Just 1
$ 18 ea.
STK437 / STK-437
Stereo Audio Power Amplifier.
NEW
Have 5
$ 28 ea.
STK439 / STK-439
Stereo Audio Power Amplifier.
NEW
Just 1
$ 33 ea.
STK441 / STK-441
Stereo Audio Power Amplifier.
NEW
Just 2
$ 39 ea.
STK459 / STK-459
Stereo Audio Power Amplifier.
NEW
Just 2
$ 39 ea.
STK750-010
STK750-010 / STK-750-010
Audio Power Amplifier
NEW
16
$ 12 ea.
STK1050
STK1050 / STK-1050
50W Audio Power Amplifier, sim. to NTE1358.
NEW
3
$ 33 ea.
STK1060
STK1060 / STK-1060
Audio Power Amplifier
NEW
1
$ 29 ea.
STK1070 II / STK-1070 II
IG04570 / IG 04570
Yamaha Yamaha Audio Power Amplifier, also marked IG 04570.
NEW
Just 2
$ 36 ea.
STK2038 / STK-2038
Stereo Audio Power Amplifier.
NEW
Just 1
$ 36 ea.
STK2125
STK2125 / STK-2125
Stereo Audio Power Amplifier.
NEW
Just 3
$ 33 ea.
STK2129 / STK-2129
Stereo Audio Power Amplifier.
NEW
SORRY, SOLD
$ 28 ea.
STK2135 / STK-2135
30W Stereo Audio Power Amplifier Output Stage. We have complete printed data sheet copies for these.
NEW
5
$ 29 ea.
STK2139 / STK-2139
35W Stereo Audio Power Amplifier Output Stage. We have complete printed data sheet copies for these.
NEW
2
$ 36 ea.
STK2250 / STK-2250
Audio Power Amplifier.
NEW
1
$ 29 ea.
STK3061Y / STK-3061Y
Audio Power Amplifier
NEW
Just 1
$ 15 ea.

CLICK for bigger PIC!


STK3062 II / STK-3062 II
Audio Power Amplifier
NEW
SORRY, SOLD
$ 15 ea.
STK3102 II
STK3102 II / STK-3102 II
Audio Power Amplifier
NEW
SORRY, SOLD
$ 15 ea.
STK3122 III
STK3122 III / STK-3122 II
Audio Power Amplifier
NEW
SORRY, SOLD
$ 15 ea.
STK4036 X
STK4036 X / STK-4036 X
50W. Audio Power Amplifier, sim. to NTE7030.
NEW
SORRY, SOLD
$ 28 ea.
STK4044 II
STK4044 II / STK-4044 II
100W. Audio Power Amplifier, sim. to NTE7031.
NEW
SORRY, SOLD
$ 38 ea.
STK4122ii, CLICK for bigger PIC!
CLICK for bigger PIC!

STK4122II
STK4122 II
SANYO SANYO Stereo Audio Power Amplifier, dual 15W. PDF Data sheet is HERE. New packed in RCA service parts bags, RCA p/n 200817.
NEW
Just 14
$ 39 ea.
STK4132 II / STK-4132 II
Stereo Audio Power Amplifier.
NEW
Just 1
$ 36 ea.
STK4161 II / STK-4161 II
Stereo Audio Power Amplifier.
NEW
Just 1
$ 39 ea.
Sanyo STK4157MK2
STK4157MK2 / STK-4157MK2
Sanyo
STEREO Audio Power Amplifier.
11
$ 39 ea.
STK4164MK2
STK4164MK2 / STK-4164MK2
Sanyo
Stereo Audio Power Amplifier, Sanyo. We have the factory data sheet for the related 4174 (in Japanese), see the links at the top of this section!
56
$24 ea.
STK4174MK2
STK4174MK2 / STK-4174MK2
Sanyo
Stereo 40W Audio Power Amplifier, Sanyo. We have the factory data sheet for this, (in Japanese), see the links at the top of this section!
45
$26 ea.
STK4231 V / STK-4231 V
Stereo Audio Power Amplifier.
NEW
Just 1
$ 36 ea.
STK4275
STK4275 / STK-4275
Audio Power Amplifier.
NEW
Just 1
$ 16 ea.
STK4332
STK4332 / STK-4332
STEREO 5W/Ch. Audio Power Amplifier.
NEW
2
$ 14 ea.
STK4352
STK4352 / STK-4352
STEREO 7W/Ch. Audio Power Amplifier, similar to NTE1218, still sealed in factory bag.
NEW
Just 3
$ 16 ea.
STK4372
STK4372 / STK-4372
SANYOSANYO STEREO 12W+12W Audio Power Amplifier, Philips factory spare parts, also marked 4822-209-32081. Interconnect and data HERE in PDF.
NEW
Have 5
$ 26 ea.
STK4803 / STK-4803
Stereo Audio Power Amplifier.
NEW
Just 2
$ 36 ea.
STK4833
STK4833 / STK-4833
STEREO 30W/Ch. Audio Power Amplifier, dual power supply, similar to NTE1820
NEW
SORRY, SOLD
$ 26 ea.
STK4843 / STK-4843
Stereo Audio Power Amplifier.
NEW
Just 1
$ 33 ea.
STK4873 /STK-4873 V
Stereo Audio Power Amplifier.
NEW
Just 1
$ 36 ea.
STK4913 / STK-4913
Stereo Audio Power Amplifier.
NEW
Just 1
$ 33 ea.
STK5332
STK5332 / STK-5332
3 O/P Voltage Regulator (VCR), similar to NTE1880.
NEW
Just 1
$ 12 ea.
STK5346
STK5346 / STK-5346
2 O/P Voltage Regulator (VCR), similar to NTE7024.
NEW
Just 1
$ 12 ea.
STK5422
STK5422 / STK-5422
Voltage Regulator.
NEW
Just 4
$ 12 ea.
STK5431ST / STK-5431ST
Voltage Regulator.
NEW
Just 1
$ 12 ea.
STK5441
STK5441 / STK-5441
3 O/P Voltage Regulator (VCR), similar to NTE1734.
NEW
SORRY, SOLD
$ 12 ea.
STK5464
STK5464 / STK-5464
3 O/P Voltage Regulator (VCR), similar to NTE7023.
NEW
Just 3
$ 12 ea.
STK5476
STK5476 / STK-5476
3 O/P Voltage Regulator (VCR), similar to NTE1881.
NEW
Just 1
$ 12 ea.
STK5482
STK5482 / STK-5482
4 O/P Voltage Regulator (VCR), similar to NTE1872.
NEW
Just 3
$ 14 ea.
STK5632D
STK5632D / STL-5632D
Power Hybrid.
NEW
Just 2
$ 8 ea.
STK6952 / STK-6952
Power Hybrid, Stepper Driver (SIP style).
NEW
Just 2
$ 15 ea.
STK7216 / STK-7216
Voltage Regulator Hybrid.
NEW
Just 5
$ 14 ea.
STK7308
STK7308 / STK-7308
Color TV Switching Regulator, similar to NTE1870.
NEW
Just 2
$ 14 ea.
STK7309
STK7309 / STK-7309
Color TV Switching Regulator.
NEW
30
$ 12 ea.
STK7348
STK7348 / STK-7348
Switching Regulator, similar to NTE7025.
NEW
Just 2
$ 14 ea.
STK7404 / STK-7404
Power Hybrid, switching regulator.
NEW
Just 2
$ 15 ea.
STK73410 II / STK-73410 II
Power Hybrid, Switching regulator.
NEW
Just 2
$ 15 ea.
PART NUMBER
DESCRIPTION
QTY.
PRICE EACH

STR3130 / STR-3130
Sanken
SANKEN, Power Voltage regulator 130V/40W, 5 lead power package, but lead 5 cut short.
NEW
Just 2
$ 10 ea.
STR9005
STR9005
Sanken
SANKEN, Power Voltage regulator, 5V with remote on-off
NEW
SORRY, SOLD
$ 12 ea.
STR30130
STR30130
Sanken
SANKEN, Power Voltage regulator 130VDC/1A, 5 lead power package.
NEW
20
$ 10 ea.
STR-F6456
STR-F6456
STRF6456
Sanken
SANKEN/Allegro, Insulated package, High power SMPS power supply regulator.
NEW
20
$ 18 ea.
STR-F6654
STR-F6654
STRF6654
Sanken
SANKEN/Allegro, Insulated package, High power (92W)/650V MOSFET sw.) SMPS power supply regulator.
NEW
12
$ 18 ea.
STR-S6824
STR-S6824
STRS6824
Sanken
SANKEN/Allegro, Insulated package, High power SMPS power supply regulator.
NEW
5
$ 22 ea.
STR-G8644G
STR-G8644D
STRG8644D
Sanken
SANKEN/Allegro, Insulated package, SMPS power supply regulator.
NEW
20
$ 14 ea.
VPS13G
VPS13G
SANYOSANYO, High voltage, high speed (350Mhz) video amplifier. CLICK HERE for PDF datasheet.
NEW
20
$ 26 ea.
IMPORTANT !
Graphical logos and trademarks are the property of their respective owners, including Tektronix, Fluke, General Radio and Hewlett Packard, and are used here merely to unambiguously identify the products. Sphere Research IS NOT a factory authorized distributor for any of the product lines indicated.

Return Home


E-Mail Us !

Godzilla GraphicsYou are visitor number .
Site Design & contents copyright 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2007, 2008, 2013, 2014, 2021 by Walter Shawlee 2 & the ad hoc Godzilla Graphics Group.
All rights reserved.
